Directional spool valve bank type DL
Product description
Throttling directional spool valves are a type of directional valve. They continuously and manually meter the flow rate in hydraulic systems with single and double-acting consumers.

The throttling directional spool valve type DL influences the speed of the consumer by throttling the pump circulation via a parallel circuit (bypass control). The close fit of the spool in the throttling directional spool valve means that the leakage is limited to a minimum for lifting functions.

The throttling directional spool valve type DL is suitable for applications in material handling and for lifting equipment.

Features and benefits:
Compact design with up to 10 segments
Various actuation variants for manual actuation
Simple pressure reductions in downstream sections using intermediate plates
Combinations possible for controlling lifting devices
Intended applications:
Material handling (industrial trucks, etc.)
Machines for agricultural and forestry purposes
Construction and construction materials machinery
